Manufacturer: BERYL Electronic Tech
Mfr. Part #: RC050M101LO8*12TH-2A1Et
Part Number: C507121
Package: Plugin,D8xL12mm
Description: 100uF 50V 630mΩ@100kHz ±20% 490mA@100kHz Plugin,D8xL12mm Aluminum Electrolytic Capacitors - Leaded ROHS
Delivers By: Saturday, March 14, 2026 *
Out of stock
📦 Standard Packaging: 500/Piece
Products Specifications
Capacitance
100uF
Operating Temperature
-40℃~+105℃
Voltage Rating
50V
Diameter
8mm
Height - Seated (Max)
12mm
Pin Spacing
3.5mm
Equivalent Series Resistance(ESR)
630mΩ@100kHz
Tolerance
±20%
Ripple Current
490mA@100kHz
Lifetime
2000hrs@105℃
Additional Information
Minimum Qty: 10
Multiple : 10
Standard Packaging: 500/Piece
