Manufacturer: DOWO
Mfr. Part #: SM712-02HTG
Part Number: C5449363
Package: SOT-23
Description: 12A 400W Bidirectional SOT-23 ESD and Surge Protection (TVS/ESD) ROHS
Delivers By: Friday, March 20, 2026 *
Out of stock
📦 Standard Packaging: 3000/Piece
Products Specifications
Reverse Leakage Current (Ir)
1uA
Peak Pulse Current (Ipp)
12A
Peak Pulse Power Dissipation (Ppp)
400W
Clamping Voltage
26V;10V
Number of Channels
2
Voltage - Breakdown
13.3V;7.5V
Operating Temperature
-55℃~+125℃
Polarity
Bidirectional
Reverse Stand-Off Voltage (Vrwm)
12V;7V
Type
ESD
pa_peak-pulse-power-dissipation-ppp
400W
Operating Temperature
pa_reverse-stand-off-voltage-vrwm
12V;7V
pa_type
ESD
pa_pa_peak-pulse-power-dissipation-ppp
400W
pa_pa_reverse-stand-off-voltage-vrwm
12V;7V
pa_pa_type
ESD
Additional Information
Minimum Qty: 10
Multiple : 10
Standard Packaging: 3000/Piece
Related Resources
- Datasheet
- EasyEDA Model
