Manufacturer: Bossie
Mfr. Part #: BX-0.8-5PLT
Part Number: C42393602
Package: SMD,P=0.8mm
Description: 1x5P 5P Tin 5 -25℃~+85℃ 500mA 1 0.8mm Brass Surface Mount,Vertical SMD,P=0.8mm Wire To Board Connector ROHS
Delivers By: Thursday, March 5, 2026 *
Out of stock
📦 Standard Packaging: 2500/Piece
Products Specifications
Manufacturer
Bossie
Package
SMD,P=0.8mm
Category
Connectors/Wire To Board Connector
Y-Width of Bottom Edge on Board
1.85mm
Pins Structure
1x5P
Number of Pins
5P
Contact Plating
Tin
Number of PINs Per Row
5
Operating Temperature
-25℃~+85℃
Current Rating
500mA
Plastic Material
LCP
Color
Beige
Number of Rows
1
Supplementary Features
Auxiliary Solder Pin
Flame Retardant Rating
UL94V-0
Pitch
0.8mm
Voltage Rating
30V
Contact Material
Brass
X-Length of Bottom Edge on Board (Spacing Line)
6.25mm
Z-Height of the Board
2.82mm
Mounting Type
Surface Mount,Vertical
Additional Information
Minimum Qty: 5
Multiple : 5
Standard Packaging: 2500/Piece
