Manufacturer: Bossie
Mfr. Part #: BX-SH1.0-8PWT
Part Number: C18077914
Package: SMD,P=1mm,Surface Mount,Right Angle
Description: 1x8P 8P SH Tin 8 -25℃~+85℃ 1A 1 1mm Brass Surface Mount, Right Angle SMD,P=1mm,Surface Mount,Right Angle Wire To Board Connector ROHS
📦 3335 in stock
Delivers By: Wednesday, November 5, 2025 *
3335 in stock
×
Total:
Bulk Pricing
1 - 4
Pieces
₹12.90
5 - 49 Pieces
₹12.90
(0% off)
50 - 149 Pieces
₹10.74
(16% off)
150 - 499 Pieces
₹9.67
(25% off)
500 - 1,999 Pieces
₹8.87
(31% off)
2,000 - 3,999 Pieces
₹8.22
(36% off)
4,000+ Pieces
₹7.89
(38% off)
📦 Standard Packaging: 2000/Piece
Products Specifications
Manufacturer
Bossie
Package
SMD,P=1mm,Surface Mount,Right Angle
Category
Connectors/Wire To Board Connector
Y-Width of Bottom Edge on Board
5.05mm
Pins Structure
1x8P
Number of Pins
8P
Reference Series
SH
Contact Plating
Tin
Number of PINs Per Row
8
Operating Temperature
-25℃~+85℃
Current Rating
1A
Plastic Material
LCP
Color
Beige
Supplementary Features
Auxiliary Solder Pin
Number of Rows
1
Pitch
1mm
Voltage Rating
50V
Contact Material
Brass
X-Length of Bottom Edge on Board (Spacing Line)
10.35mm
Z-Height of the Board
3.15mm
Mounting Type
Surface Mount, Right Angle
Additional Information
Minimum Qty: 5
Multiple : 5
Standard Packaging: 2000/Piece
