Manufacturer: Bossie
Mfr. Part #: BX-XH2.54-5PZZ-R
Part Number: C22388501
Package: Through Hole,P=2.54mm
Description: 1x5P XH 5P Tin 5 -25℃~+85℃ 3A 1 2.5mm Copper Alloy Through Hole Through Hole,P=2.54mm Wire To Board Connector ROHS
📦 7270 in stock
Delivers By: Wednesday, November 5, 2025 *
7270 in stock
×
Total:
Bulk Pricing
1 - 9
Pieces
₹5.40
10 - 99 Pieces
₹5.40
(0% off)
100 - 299 Pieces
₹4.50
(16% off)
300 - 999 Pieces
₹4.06
(24% off)
1,000 - 4,999 Pieces
₹3.72
(31% off)
5,000 - 9,999 Pieces
₹3.46
(35% off)
10,000+ Pieces
₹3.32
(38% off)
📦 Standard Packaging: 1000/Piece
Products Specifications
Manufacturer
Bossie
Package
Through Hole,P=2.54mm
Category
Connectors/Wire To Board Connector
Y-Width of Bottom Edge on Board
5.75mm
Pins Structure
1x5P
Reference Series
XH
Number of Pins
5P
Contact Plating
Tin
Number of PINs Per Row
5
Operating Temperature
-25℃~+85℃
Current Rating
3A
Plastic Material
PA66
Color
Red
Number of Rows
1
Flame Retardant Rating
UL94V-0
Pitch
2.5mm
Voltage Rating
250V
Contact Material
Copper Alloy
X-Length of Bottom Edge on Board (Spacing Line)
15mm
Z-Height of the Board
7mm
Mounting Type
Through Hole
Additional Information
Minimum Qty: 10
Multiple : 10
Standard Packaging: 1000/Piece
