Manufacturer: Ai-Thinker
Mfr. Part #: NF-04-MI-2.4G
Part Number: C129093
Package: SMD,12x18mm
Description: Transmit and receive -96dBm 2.4GHz On-board PCB antenna SMD,12x18mm RF Modules ROHS
Delivers By: Saturday, March 14, 2026 *
Out of stock
📦 Standard Packaging: 45/Piece
Products Specifications
Model
Transmit and receive
Output Power(Max)
4dBm
Modulation System
GFSK
Sensitivity
-96dBm
Operating Temperature
-20℃~+70℃
Voltage - Supply
1.9V~3.6V
Frequency
2.4GHz
Antenna Type
On-board PCB antenna
Interface Type
SPI
Receive Current
16.5mA
Send Current
18mA
Additional Information
Minimum Qty: 1
Multiple : 1
Standard Packaging: 45/Piece
Related Resources
- Datasheet
- EasyEDA Model
