Manufacturer: Broadcom/AVAGO
Mfr. Part #: ACPL-217-500E
Part Number: C2939626
Package: SOP-4-2.8mm
Description: 80V 3.75kV 50mA 400mV@8mA,2.4mA 1 9V 1.2V SOP-4-2.8mm Transistor, Photovoltaic Output Optoisolators ROHS
Delivers By: Wednesday, March 18, 2026 *
Out of stock
📦 Standard Packaging: 3000/Piece
Products Specifications
Manufacturer
Broadcom\u002FAVAGO
Package
SOP-4-2.8mm
Category
Optoisolators/Transistor, Photovoltaic Output Optoisolators
Load Voltage
80V
Operating Temperature
-55℃~+110℃
Rise time
2us
Isolation Voltage(Vrms)
3.75kV
Output Current
50mA
Vce Saturation(VCE(sat))
400mV@8mA,2.4mA
Number of Outputs
1
Reverse Voltage
9V
Voltage - Forward(Vf)
1.2V
Current Transfer Ratio (CTR) Maximum\u002FSaturation Value
600%
Current Transfer Ratio (CTR) Minimum
50%
Output Type
Phototransistor
Additional Information
Minimum Qty: 1
Multiple : 1
Standard Packaging: 3000/Piece
