Manufacturer: STMicroelectronics
Mfr. Part #: SCTH70N120G2V-7
Part Number: C3288434
Package: H2PAK-7
Description: H2PAK-7 Silicon Carbide Field Effect Transistor (MOSFET) ROHS
Delivers By: Sunday, April 12, 2026 *
Out of stock
📦 Standard Packaging: 1000/Piece
Products Specifications
Manufacturer
STMicroelectronics
Package
H2PAK-7
Category
Silicon Carbide (SiC) Devices/Silicon Carbide Field Effect Transistor (MOSFET)
Gate Threshold Voltage (Vgs(th)@Id)
4.9V
Type
1 N-Channel
Pd - Power Dissipation
469W
Current - Continuous Drain(Id)
90A
RDS(on)
30mΩ
Drain to Source Voltage
1200V
Reverse Transfer Capacitance (Crss)
28pF
Ciss-Input Capacitance
3540pF
Gate Charge(Qg)
150nC
Operating Temperature
-55℃~+175℃
Output Capacitance(Coss)
176pF
Additional Information
Minimum Qty: 1
Multiple : 1
Standard Packaging: 1000/Piece
Related Resources
- Datasheet
- EasyEDA Model
