Manufacturer: Diodes Incorporated
Mfr. Part #: ZXTN620MATA
Part Number: C526809
Package: W-DFN-3(2x2)
Description: 80V 12W 110@1A,2V 3.5A NPN W-DFN-3(2x2) Bipolar (BJT) ROHS
Delivers By: Friday, March 20, 2026 *
Out of stock
📦 Standard Packaging: 3000/Piece
Products Specifications
Manufacturer
Diodes Incorporated
Package
W-DFN-3(2x2)
Category
Transistors/Thyristors/Bipolar (BJT)
Current - Collector Cutoff
100nA
Collector - Emitter Voltage VCEO
80V
DC Current Gain
110@1A,2V
Pd - Power Dissipation
12W
Operating Temperature
-55℃~+150℃
Current - Collector(Ic)
3.5A
Transition frequency(fT)
160MHz
Vce Saturation(VCE(sat))
185mV
type
NPN
Additional Information
Minimum Qty: 1
Multiple : 1
Standard Packaging: 3000/Piece
Related Resources
- Datasheet
- EasyEDA Model
